Client state management, sync engines, and Foundry

I wrote about automated client state management a bit last year. I think it is the single greatest untapped source of productivity for building on Foundry.

Any data-intensive web or mobile application with a central server has the job of synchronizing data while the user interacts with it. Reframed, every application is actually a distributed system. We don't typically talk about applications this way -- the backend devs that might have this realization are off working on backend things -- but we can get to better solutions if we do.

The typical approach to this synchronization problem usually boils down to some version of:

• Fetch data from an API (REST, GraphQL, etc.), assuming little to nothing about the structure of the underlying data besides having a notion of resources with unique keys
• Cache resources locally in a key/value store
• Give the developer some facilities to imperatively update or invalidate the cache in response to user actions and subsequent server responses

Web frameworks like Next.js do a version of this. Popular client libraries like useSWR and React Query do a version of this. The Relay and Apollo GraphQL frameworks do a slightly enlightened version of this, relying on layering a Global Object Identification Specification on top of vanilla GraphQL.

This approach is bad! Cache invalidation is typically considered one of the two hardest problems in computer science, so we should solve it at the system level rather than leaving developers to solve it themselves.

"And to put it bluntly, they are all in the same stage of elaborately learned superstition as medical science was early in the last century, when physicians put their faith in bloodletting, to draw out the evil humors which were believed to cause disease. With bloodletting, it took years of learning to know precisely which veins, by what rituals, were to be opened for what symptoms. A superstructure of technical complication was erected in such deadpan detail that the literature still sounds almost plausible."

-- Jane Jacobs, The Death and Life of Great American Cities

What we really want is declarative data synchronization. React lets us describe how we want our UI to look as a function of our data, and it uses a reconciliation algorithm to efficiently coordinate updates to our UI. In the same way, we should be able to declare the data our UI needs, and a sync engine should work out how to efficiently fetch that data and keep it up-to-date in response to both local and remote changes.

There's a growing movement closely related to this idea, and the most promising framework in development is Zero. You should look at their docs, but I'm reproducing their sample code here.

function Playlist({ id }: { id: string }) {
    // This usually resolves *instantly*, and updates reactively
    // as server data changes. Just wire it directly to your UI –
    // no HTTP APIs, no state management no realtime goop.
    const tracks = useQuery(
        zero.query.playlist
            .related("tracks", (track) =>
                track.related("album").related("artist").orderBy("playcount", "asc")
            )
            .where("id", id)
    );

    const onStar = (id: string, starred: boolean) => {
        zero.track.update({
            id,
            starred,
        });
    };

    return (
        <div>
            {tracks.map((track) => (
                <TrackRow track={track} onStar={onStar} />
            ))}
        </div>
    );
}

Zero allows you to declare data requirements for a particular component, and it will automatically keep the data up-to-date as it changes both locally and remotely. It's built on a theory of "incremental view maintenance" (you can find the main paper Zero takes inspiration from here) or IVM, which answers the question of how to update the results for queries after data is updated more efficiently than just re-running the queries.

And this theory generalizes a lot better thank you might think! There's another company (which appears to be spun out of the research linked above) called Feldera which offers an incremental compute engine for the entire SQL specification, including more advanced features like aggregations and windowing. It even handles relative time filters.

In the ideal framework I should be able to write a generic component with data dependencies and mutations, freely compose it with other components, and everything should just work.

As a concrete example let's consider what it would look to replace a SaaS app like Calendly. Calendly lets you embed their scheduling component with an iFrame, and gives you a callback for when an event is booked. The resulting booking data lives in Calendly, and the developer is left to cobble everything together. We should be able to replace this with an abstract scheduling component -- ideally built on a standard scheduling interface -- that loads data for times that can be scheduled and performs mutations for bookings. When I perform a booking, other parts of my app that might use that data, say an upcoming appointments list, should automatically update.

Between ideas from Zero and Foundry (via OSDK and Workshop) and GraphQL (via Relay) we're circling around the ideal solution. There are four ideas in particular to focus on: read composability, write synchronization, rich semantic modeling, and rich querying.

Read composability

For reads to compose, components need to be able to declare their data requirements without being responsible for actually fetching it, so we can bundle up the data requirements for an entire UI tree into a single efficient query. Relay has a good video about this that is really worth watching, and a good blog post. I'll reproduce the key parts of the blog post here.

In component-based UI systems such as React, one important decision to make is where in your UI tree you fetch data. While data fetching can be done at any point in the UI tree, in order to understand the tradeoffs at play, let’s consider the two extremes:

• Leaf node: Fetch data directly within each component that uses data
• Root node: Fetch all data at the root of your UI and thread it down to leaf nodes using prop drilling

Relay leverages GraphQL fragments and a compiler build step to offer a more optimal alternative. In an app that uses Relay, each component defines a GraphQL fragment which declares the data that it needs. This includes both the concrete values the component will render as well as the fragments (referenced by name) of each direct child component it will render.

At build time, the Relay compiler collects these fragments and builds a single query for each root node in your application. Let’s look at how this approach plays out for each of the dimensions described above:

• ✅  Loading experience - The compiler generated query fetches all data needed for the surface in a single roundtrip
• ✅  Suspense cascades - Since all data is fetched in a single request, we only suspend once, and it’s right at the root of the tree
• ✅  Composability - Adding/removing data from a component, including the fragment data needed to render a child component, can be done locally within a single component. The compiler takes care of updating all impacted root queries
• ✅  Granular updates - Because each component defines a fragment, Relay knows exactly which data is consumed by each component. This lets relay perform optimal updates where the minimal set of components are rerendered when data changes

The reason this works in Relay is that GraphQL is a composable query language where the results match the shape of the query. SQL doesn't have this property -- it gives you flat results that don't match the shape of your query. Palantir's Object Set API has the same problem, which is why OSDK queries aren't composable. Workshop (Foundry's no-code app builder) is built on the same API, which is part of why Workshop apps have crazy request waterfalls. Zero has a custom query language called ZQL that is very intentionally composable.

Besides query composability, there are some framework features also needed for true read composability. One is the ability to dynamically choose which properties to load for generic components like Workshop's Object Table. Relay doesn't allow this because its compiler wants query definitions to be totally static aside from GraphQL variables for performance and security reasons (e.g. so it can support persisted queries). These decisions make sense as defaults for Facebook, but not for most apps. Zero collects subqueries into full queries more simply without a compiler, which should allow for dynamic queries. This is on net probably the best solution, and Zero could probably layer in a compiler later for sites that need to be hyper-optimized like Facebook.

Another feature needed is support for React Suspense. In this context, Suspense lets us decouple loading states from components, so if I'm pulling in multiple components I maybe didn't write into my app, I can compose them and provide a single loading state that wraps them rather than relying on their individual pre-baked loading states and ending up with inconsistent UI that I don't want in my app.

import { SchedulingComponent } from "scheduling-library";
import { CalendarComponent } from "calendar-library";

// ...

<Suspense fallback="Loading...">
    <SchedulingComponent {...props} />
    <CalendarComponent {...props} />
</Suspense>;

Relay is built on Suspense, Zero doesn't have it yet but it should be relatively easy to add.

Summary:

• ❌  Foundry + OSDK
• ❌  Foundry + Workshop
• ✅  GraphQL + Relay
• ✅  Zero

Write synchronization

For components to compose with respect to writes, mutations triggered from one component should be automatically reflected in other components on the page without those components needing awareness of each other. This means components need to be writing and subscribing to the same frontend datastore.

Zero's sync engine inherently provides full write synchronization, as explained not just between components on a single page but between users working on different machines. Relay maintains a normalized store, which means that it will handle keeping components that reference the same data in sync, but it doesn't have any real notion of concepts like filters or sorts or aggregations so if your query involves any of those you are left to orchestrate store updates in response to mutations yourself. Workshop does something similar to Relay but a bit more automatic. For example, it will realize after an Action that it might need to invalidate particular queries and will refetch them. But it doesn't do anything in the way of IVM so it does a lot more work than it needs to which results in both way more load on the database and a much worse user experience.

Summary:

• ❌  Foundry + OSDK
• ⚠️  Foundry + Workshop
• ⚠️  GraphQL + Relay
• ✅  Zero

Rich semantic modeling

Modern programming languages all have rich types and facilities for polymorphism, which are critical for expressing and maintaining programs. In a distributed object system we also need fine-grained mutations to express transactional business logic, and explicit relationships between object types.

GraphQL actually does a pretty good job here. Its type system is pretty rich, including arrays, nested types, enums, custom scalars, and nullability. It provides fine-grained mutations, and polymorphism through interfaces and unions.

Foundry's Ontology has an even more rich type system. It doesn't have unions (yet) but has a better version of interfaces than GraphQL that enables the same code to work across heterogenous organizations via features like interface property mapping. For custom constrained types it has Value Types. For mutations it has Actions, which can be defined with code or with simple declarative rules. It has explicit relationship configuration via Link Types.

Zero's schema configuration is very limited in its type system right now, only allowing strings and numbers and booleans. It has relationships but doesn't have fine-grained mutations (yet), and doesn't have any polymorphism.

Summary:

• ✅  Foundry + OSDK
• ✅  Foundry + Workshop
• ✅  GraphQL + Relay
• ❌  Zero

Rich querying

Embracing a rich query language in our applications (e.g. SQL) rather than treating a database as a dumb key/value store to be abstracted over lets us completely avoid the traditional work of hand-crafting RPC endpoints for UI views. You might still write query functions for custom logic, but no more writing endpoints for getBook, getBooks, searchBooks. This obviously requires our database layer to handle permissions, but securing data is part of the purpose of a database!

GraphQL goes a tiny bit in this direction in that it doesn't require us to define exact query patterns up front, but it's not really a rich query language in that it has no concept of filters, sorts, aggregations, unions, intersections, etc.

Zero's ZQL is specifically a rich query language, as is Palantir's Object Set API that OSDK is built on.

One obvious critique of embracing rich query languages is concern for intentional DDOS attacks and unintentional DDOS from someone forgetting to add the right database indexes. Relay has a "persisted queries" feature as an answer to this that could also be applied to rich query languages, where query shapes for an application are statically analyzed before deployment so that queries at runtime can be restricted to those shapes. In fact, "ability to lock queries down to only expected forms for security" is on the Zero roadmap. On the database indexes point, I really think we should move past manually enumerating database indexes anyway and towards either (1) indexing everything (a la Elasticsearch, Foundry, Firebase) (2) using static analysis of the queries in an application (which is enabled by embracing a rich query language!) to automatically figure out what indexes we should create or (3) automatically maintaining indexes at runtime based on actual queries (a la AlloyDB).

Summary:

• ✅  Foundry + OSDK
• ✅  Foundry + Workshop
• ❌  GraphQL + Relay
• ✅  Zero

Synthesizing these ideas, our goal is to collapse the traditional three-tier architecture into a single rich programming environment. Shyam had a good thread around this idea a few years ago.

Shyam Sankar

@ssankar

·Follow

Replying to @ssankar

3/ 12 @petewilz on Why is Ontology a category-defining piece of technology? Traditionally, software systems have gravitated towards a partitioned model for data - a physical model for the database, a logical model for applications, and a conceptual model for users.

1:54 AM · Jan 25, 2023

36

Reply

Copy link

Read 1 reply

Embracing a rich query language lets us avoid isolating the database tier. Embracing rich semantic modeling we've grown to expect from modern programming languages lets us avoid isolating the logic tier. Foundry's Ontology system does both of these already, enabling composability at the application level that helps drive the marginal cost of integrating the next application towards zero. A sync engine that provides read composability and write synchronization achieves the final piece, enabling composability at the component level, which lets us avoid isolating the client tier (on top of just making UI programming generally way easier to reason about).

Returning to our original example, Calendly is nominally a $3B business and does around $300M in revenue. Given that Calendly is little more than a scheduling widget, we can think about that revenue as a component integration tax. And the end result isn't even good! With the right framework we can recapture all this value for organizations actually doing things. Multiply this out over the hundreds of SaaS products that organizations try to stitch together to function (probably thousands if you consider transitive dependencies), and it's clear we'll be able to run efficient organizations with far fewer resources, helping them create far better products and services, which will have a radical effect on how we organize our entire economy.

Zero’s architecture here is a good model. In Foundry, the equivalent of zero-cache (Zero's incremental query engine) would be implemented as an Object Database, analogous to Postgres replication slots which Zero supports now. The nascent real-time support in OSDK is backed by an Object Database called Object Set Watcher, which does what it sounds like. It handles permissions properly but does only a super limited version of IVM and returns flat results, similar to what Electric SQL does with "shapes". As explained, this approach forces developers to do all sorts of contortions to actually build anything outside of toy apps. One interesting idea in Electric's design that wouldn't work with Zero is that it uses long-polling rather than WebSockets, which means it can include HTTP cache headers in responses so it works out-of-the-box with highly optimized reverse proxies like Nginx and CDNs like Cloudflare. This gives Electric a structural advantage in the short-term but again leaves write synchronization to the developer to solve so I don't think this idea wins in the end.

The open questions for bringing Zero's ideas to Foundry in my mind are:

• Do we want a new query language? As explained SQL doesn't work well for user interfaces. Figma's LiveGraph made an interesting choice of using GraphQL as their query language. Their architecture isn't right (it's closer to Electric and Object Set Watcher with a hack for following links that match Figma's particular query patterns) but using GraphQL as the query language has the nice property of enabling compatibility with lots of existing tooling. GraphQL's concepts also mostly map nicely to Ontology concepts, though GraphQL interfaces don't have anything like property mapping, GraphQL fundamentally can't handle building queries that involve unions/intersections, and GraphQL can't handle runtime calculations (which are coming soon to Ontology) so adopting it would require leaving a lot on the table. ZQL doesn't have any polymorphism or rich semantic modeling yet but otherwise has sound ideas, which leads me to my second question.
• Should we just make a Foundry adapter for Zero? My concern is given that Zero is trying to support many backends (Postgres, SQLite, etc.) it'll just support the least common denominator of those systems for a while, which means it will be hard to support Ontology's semantic modeling. Zero also needs some other features like Suspense support, custom mutations (which are coming soon), and online writes for user actions that should block (e.g. swapping aircraft, placing an order), but these should all be relatively easy to add.

I don't have the answers to these questions! But they should become clear once we start working on this.

Separately, there are some things Palantir should work on to properly support a sync engine regardless:

• Distinguishing Functions that can be executed in arbitrary JS/WASM environments. For "local-first" style applications with offline writes, we need to be able to figure out how the data is going to change on the client after Actions are executed. For declarative Action rules we can easily replicate the logic on the client, but for Function-backed Actions we need to be able to download and execute the logic on the client. Obviously this isn't feasible for Functions backed by Compute Modules since we're not going to run containers in the browser, but standard TypeScript Functions already target an isomorphic JavaScript runtime, and Python Functions could target Pyodide if they don't use any exotic dependencies. This also will only work for Actions that don't have side effects in their logic, which we can infer by checking if the Function uses any egress policies. It's actually really great that Actions mostly separate out side effects with Webhooks so we can automatically figure out which logic to run in the client. Basically this exact point is made here in this post looking at different approaches to central server collaboration (which is very worth reading). A nice side effect of building this also is we could speed up existing Workshop modules that use Functions and prevent new modules from needing to fall back to variable transformations.
• An open Ontology specification. I'm going to make a larger argument for this idea soon, but having an open version of the Ontology (maybe with an open-source Postgres-based reference implementation) would enable collaborating on a sync engine in public (maybe Zero could use this specification instead of their own scoped down version) and would enable an ecosystem of components.

If you landed here without knowing what Foundry is, the docs and developers YouTube channel are good places to start. It's an operating system for organizations -- a single, programmable layer where all data is stored, all decisions are made, and all applications are built. It's a magical piece of technology and there's a free tier now that you should play with. The Ontology docs are of particular interest here, as is this blog post.
